Motive Deep Cycle AGM Battery
EVF Deep Cycle AGM Battery is specially designed for frequent deep cycle discharge. By using the specially designed active material and strong grids, the EV series sealed lead acid battery offers reliable performance in high load situations and can deliver more than 300 cycles at 100% DOD. Suitable for mobility scooters, electric wheel chairs, golf buggies etc.
Capacity: 40-260Ah
Volt: 12V
Specifications for the SPACEFLIGHT POWER Motive Deep Cycle AGMBattery:
| MODEL | VOLTAGE (V) | 3HR CAPACITY (AH) | 5HR CAPACITY (AH) | SIZE (MM) | WEIGHT ±2% (KG) | TERMINAL SIZE |
|---|---|---|---|---|---|---|
| 3-EVF-200 | 6 | 200 | 230 | 258 × 182 × 270 × 274 | 35 | M8 × Φ20 |
| 3-EVF-260 | 6 | 260 | 300 | 350 × 180 × 268 × 272 | 46 | M8 × Φ20 |
| 4-EVF-150 | 8 | 150 | 170 | 258 × 182 × 270 × 273 | 36 | M8 × Φ20 |
| 6-EVF-40 | 12 | 40 | 46 | 222 × 118 × 175 × 178 | 21 | M6 × Φ16 |
| 6-EVF-60 | 12 | 60 | 70 | 262 × 165 × 165 × 168 | 24 | M6 × Φ16 |
| 6-EVF-80 | 12 | 80 | 92 | 260 × 169 × 209 × 212 | 26.5 | M6 × Φ16 |
| 6-EVF-100 | 12 | 100 | 115 | 330 × 172 × 215 × 218 | 35 | M8 × Φ18 |
| 6-EVF-120 | 12 | 120 | 138 | 405 × 171 × 237 × 240 | 41 | M8 × Φ18 |
| 6-EVF-150 | 12 | 150 | 173 | 485 × 171 × 240 × 243 | 52 | M8 × Φ20 |
| 6-EVF-200 | 12 | 200 | 230 | 517 × 240 × 220 × 223 | 61 | M8 × Φ20 |
General Features:
● Pb-Ca-Sn alloy, no Cd,environmentally-friendly
● High purity raw material and high-performance AGM separator
● Excellent low-temperature property and vibration resistance
● Excellent cycle life and recovery performance during deep cycle use
● Sealed construction and Maintenance free
Compliant Standards:
GB/T 22199-2008、GB/T18332.1-2009、Passed ISO9001、ISO14001、ISO18001、CE certificate
Spaceflight Power Motive Deep Cycle AGM Battery Applications
Motive Deep Cycle AGM Batteries are ideal for electric vehicles, golf carts, forklifts, floor sweepers, solar and wind energy storage systems, uninterruptible power supplies (UPS), telecommunications base stations, marine vessels, and recreational vehicles (RVs).
